Product Features:
1. Precision Airflow & Low-Noise Operation
Safety and comfort go hand-in-hand. The AY-FH-F2 is optimized for stable airflow dynamics, ensuring a consistent 0.5 m/s standard face velocity across the sash opening to prevent toxic backflow.
High Exhaust Capacity: Powered by an energy-efficient 110W motor, it delivers a robust 1800m³/h exhaust volume through a standard 250mm diameter exhaust collar.
Whisper-Quiet Environment: Engineered for minimal vibration and noise disruption, operating at a low 50dB, allowing researchers to communicate and focus without the constant roar of industrial ventilation.
2. Dual-Zone Anti-Corrosion Architecture
Chemical handling requires uncompromising defense against spills and vapors. The AY-FH-F2 utilizes a smart, dual-material construction strategy:
Rugged Exterior: The main cabinet body is constructed from 1.0mm thick cold-rolled steel (CRS). It undergoes a meticulous acid-washing pre-treatment before being finished with a durable white epoxy resin powder coating. This provides excellent structural integrity and resistance to ambient laboratory humidity and mild chemical exposure.
Impervious Interior Workzone: The internal cavity where chemical reactions actually occur is lined with 5mm thick Compact Laminate (Anti-Beite) board. This non-porous, high-density material offers superior resistance to strong acids, alkalis, and organic solvents, ensuring that accidental spills won’t degrade the hood’s safety integrity over time.
3. Premium Worktop Solutions
The work surface takes the most physical abuse. The AY-FH-F2 comes standard with a 12.7mm thick black solid phenolic resin worktop, renowned for its excellent chemical resistance, heat resistance (up to 180°C), and anti-bacterial properties.
Customizable Options: Depending on your specific applications, you can upgrade the worktop to:
Ceramic: Ultimate resistance to extreme heat and concentrated strong acids (e.g., Hydrofluoric acid).
Stainless Steel (SUS304/316): Ideal for radioactive isotope handling or applications requiring strict cleanability.
Marble: Cost-effective solution for light-duty chemical and physical testing.
4. Ergonomic Utilities & Smart Configuration
A fume hood is only as good as its utility setup. The AY-FH-F2 is thoughtfully designed to support your benchtop equipment:
Why Choose AY-FH-F2?
Compliance Ready: Engineered to meet the crucial 0.5m/s face velocity required by ASHRAE 110 and SEFA standards.
Cost-Effective Maintenance: The separate epoxy exterior and anti-beite interior mean you only replace the interior liner in case of catastrophic damage, saving thousands compared to replacing a full stainless steel hood.
Versatile Application: Perfect for general chemistry, wet labs, educational demonstrations, pharmaceutical sample prep, and quality control (QC) testing.
Product Parameters:
| Model | AY-FH-F2 |
| Air Volume | 1800m³/h |
| Exhaust Outlet Diameter | 250mm |
| Fan Power | 110w |
| Lighting Power | LED20W |
| Rated Power | 2000w |
| Noise Level | 50db |
| Face Velocity | 0.5m/s |
| Voltage | 220v |
| Cabinet Body | 1.0mm cold-rolled steel with epoxy coating (White) |
| Working Chamber | 5mm acid & alkali resistant compact laminate |
| Countertop Material | 12.7mm solid phenolic resin (Black); Ceramic/Marble/SS available |
